Dryer Trouble Shooting
Tumbler turns but no spark at burner Glass fuse Check small glass control fuse in back of
dryer. Replace if failed.
Thermostat Check if voltage is passing through the
two wires attached to the temoprature
thermostat
Ignition Check for 24VAC output from transformer.
Transformer Replace if have 120V between black & white
and no 24V between red and yellow.
Over temperature Check to see if manually resettable
thermostat. Thermostat is kicked out. Reset
by pushing red reset button.
Ignition control Check for 24VAC coming into the control
on the at burner red wire. If voltage, then
check for 24VAC out on the brown wire. Also
check for spark at the ignitor. If no 24VAC
output or no spark to the ignitor, replace
ignition control.
Air Flow Switch Check air ow switch to be sure it closes
when dryer is running. If not, adjust or
replace switch.
Hi-limit Check for continuity. Should be 0 ohms
resistance when cold. If not, replace
thermostat.
Gas supply No gas can cause system lockout
Symptom Probable Cause Suggested Remedy
Tumbler does not turn Drive belts Check both drive belts. Replace if failed.
Tumbler does not turn Check capacitor and motor. Replace if failed
Door switch Check door switch contacts and adjustment.
Adjust or replace door switch.
Timer Tumbler does not turn Check to see if heat timer is turned on
Part # 8533-076-001 11/13
