Dexter Power PC1300RT - Direction of Feed; Operation; Speed Adjuster; ON;OFF Switch

5. BEFORE PUTTING THE EQUIPMENT INTO OPERATION
Direction of feed
The feed motion of the router must always be carried out against the rotation direction of the router bit (up-grinding).
When milling in the direction with the rotation of the router bit (down-cutting), the router can break loose, eliminating control by the user.
6. OPERATION
Speed adjuster:
With the thumbwheel, the required speed can be selected (also while running).
Min-2 low speed
3-4 medium speed
5-Max high speed
Material Router Speed stages
Hardwood
(Beech)
4-10 mm
12-20 mm
22-40 mm
5-6
3-4
1-2
Softwood
(Pine)
4-10 mm
12-20 mm
22-40 mm
5-6
3-6
1-3
Particle board
4-10 mm
12-20 mm
22-40 mm
3-6
2-4
1-3
Plastic
4-15 mm
16-40 mm
2-3
1-2
The values shown in the chart are standard values. The necessary speed depends on the material and the operating conditions, and can be
determined by practical testing.
After longer periods of working at low speed, allow the machine to cool by running for approx. 3 minutes at maximum speed with no load.
ON/OFF switch
The tool is equipped with a lock-off button to avoid unintentional starting.
WARNING: Before plugging the tool into the power point always check that the
trigger switch and lock-off button work properly.
To switch on, depress the lock-off button and squeeze the trigger switch.
To switch off, release the trigger switch.
25
EN
