2.8.8 CPU Fan Connector
The processor must be kept cool by using a fan with heatsink.
Connect the CPU fan to the 3-pin fan connector at location J5 on
the system board.
Pin
1
2
3
Function
On/Off
+12V
Sense
Pin
1
2
3
4
5
Function
VCC
N. C.
IRRX
Ground
IRTX
