52-1335 Pin Assignment
D-Sub 15 - connector 5
1
8
9
15
Label Pin
TypePin Label
Aout1
1
2
9
10
11
3
LINE out 2+
LINE out 2-
SHIELD
Aout2
13
14
6
LINE out 4+
LINE out 4-
SHIELD
Aout4
Type
LINE out 1+
LINE out 1-
SHIELD
Aout3
HP1
4
5
12
7
8
15
LINE out 3+
LINE out 3-
SHIELD
HP 1 L
HP 1 R
HP COM RETURN
