7
Step
2
Attach R to B with and .
X 2
B
R
X 2
3
5
3
5
The top of Mechanism R may look
different due to the movable joints.
Please determine the orientation based
on their bottom sides.
B
Mechanism R should be attached on the
inside of Arm B that without nail heads.
Nail heads on Arm B towards outside.
