DHP 5440096 - Hardware Components Identification; Main Structural Hardware; Ladder and Base Components

3 /15
HARDWARE
KING SUPPORT
T905600
QTY: 2
BOTTOM BRACE
T905610
QTY: 2
UPPER BRACE
T905620
QTY: 2
A
B
C
D
NOTE: PARTS , , & HAVE PROTECTIVE END CAPS PRE-INSTALLED
D
J
E
RIGHT BASE
T905630
QTY: 1
LEFT BASE
T905690
QTY: 1
E
HOLE
AGUJERO
RIGHT GUARD RAIL
T905640
QTY: 1
F
LEFT GUARD RAIL
T905650
QTY: 1
HOLE
AGUJERO
HOLE
AGUJERO
B
A
C
D
E
F
UPPER SIDE RAIL
T905660
QTY: 1
G
G
HOLE
AGUJERO
HOLE
AGUJERO
H
LADDER SIDE RAIL
T905670
QTY: 1
H
HOLE
AGUJERO
LOWER SIDE RAIL
T905680
QTY: 1
I
J
I
F
B34544009600
NO HOLES
0 AGUJEROS
J
SAFETY BRACKET
T391730
QTY: 2
V
