DieHard 71496 - Troubleshooting; Specifications

• 8 •
TROUBLESHOOTING10.
PROBLEM REASON SOLUTION
Red LED is on, audible
alarm is on, and/or inverter
does not function.
Poor contact at terminals.
Fuse Blown.
Inverter shutdown.
Inverter may not be working
properly.
Unplug and reinsert the
12-volt plug or check
connections at power supply.
See “IF THE INVERTER
FUSE BLOWS” section.
See “LED INDICATOR AND
SHUTDOWN PROTECTION”
section.
See Warranty and call
Customer Service 1-800-
732-7764 (Hours: 7 am – 5
pm CST).
The red LED is lit and the
green LED is not.
12V Accessory Plug or
Clips are not making a good
connection to the battery.
Connections are reversed.
Inverter may not be working
properly.
Check for poor connection to
battery and frame. Make sure
connection points are clean.
Rock clips back and forth for
a better connection.
Unplug the charger and
reverse the clips.
See Warranty and call
Customer Service 1-800-
732-7764 (Hours: 7 am – 5
pm CST)
SPECIFICATIONS11.
Maximum Continuous Power 425 Watts
Surge Capability (Peak Power) 850 Watts
No Load Current Draw <0.4A
Wave Form Modied Sine Wave
Input Voltage Range 10.5V – 15.5V DC
Output Voltage Range 110V ± 5% AC
Low Battery Alarm Audible, 11V ± 0.3V DC
Low Battery Shutdown 10.5V ± .3V DC
High Battery Shutdown 15.5V ± 0.5V DC
Optimum Efciency 85%
AC Outlet Two, NEMA 5 - 15 USA
Fuse Two, 25-Amp (Spade Type)
Dimensions 6.5” L x 4.13” W x 2.2” H
Weight approximately 2 lbs.
