DIGGERKING King 2.3 Digger User Manual

46
S/N
Name
Description
1
Water temperature
warning lamp
When the water temperature is >105℃, the warning lamp starts to
flash and at the same time the
buzzer sounds.
2
Fuel warning lamp
When the fuel level reaches 10%, the warning lamp starts to flash
and at the same time the buzzer sounds.
3
Engine oil pressure
indicator lamp
After the start of engine, if the engine oil pressure is too low, the
warning lamp starts to flash and at the same time the buzzer
sounds. In such case, stop the engine and
check.
4
Charging indicator
lamp
After the start of engine, if the green charging indicator lamp keeps
on, it indicates the normal charging. If this lamp fails to turn on after
start of engine, it indicates the abnormal charging. Stop the engine
and check.
5
Preheater indicator
lamp
If this lamp turns on, it indicates that the engine preheater is
working. If this lamp is not on, it indicates that the preheater is not
working.
6
High/low speed
indicator lamp
If this indicator lamp turns on, it indicates that the system is under
high
-speed mode. If this indicator lamp is not on, it indicates that
the system is under
low-speed mode.
7
Water temperature
gauge
It indicates the variation of coolant temperature in range of 40℃-
120
℃. The area from white zone
to the red zone indicates the gradual increasing of temperature.
When the red zone is reached, it indicates that the coolant
temperature is too high. Stop the engine, wait for it to cool down,
and then
restart the engine.
8
Hour meter
It indicates the number of working hours in range of 0-99999.9h. It
starts the timing after the start
of engine. In such case, the
 flashes.
9
Fuel gauge
It indicates the variation of fuel level in range of 10%-100%. The
area from white zone to the red zone indicates the gradual
increasing of fuel level. Generally, the fuel level varies within the
green zone. If the red zone is reached, it indicates insufficient fuel in
the fuel tank. Please refuel timely.
When the key switch is rotated to ON, the instrument starts the pre-working self-examination.
In such case, all indicator lamps turn on, the pointers return to zero position, and the buzzer
sounds. The system completes the self
-examination in 3S and then enters the normal working
mode. If the lamp fails to turn on, it indicates presence of malfunctions. Please contact
local
dealer or service personnel
for careful checking.
