64
Swing the bucket towards the track entrapped in the mud.
Set the angles at 90~110° for bucket arm and boom.
Push the bucket bottom (Not bucket teeth) onto the ground.
Place a wood plate or similar object beneath the lifted track.
Lift the bucket and drive out the machine from the mud slowly.
Entrapment of Both Tracks in Mud
Place the bulldozing blade to the opposite side of the digging zone.
It’s preferable to dig by shallow depth and large travel. The maximum digging force is achieved
when the angle between boom and bucket arm is 80~120°. It’s preferable to change the angle for
effective digging.
Loading
Install a bucket suitable for digging of ditches, adjust the tracks to be parallel with the ditch to be
dug, in order to improve the working efficiency. While digging a wide ditch, dig the side faces and
then the middle area.
Digging of Side Drainage Ditch
While loading soil into the cargo body of a truck, loading from the rear end of truck can load
more soil easier than loading from the front end. In addition, the small angle slewing can be used
to improve the efficiency.
Leveling
As shown in the diagram, dig the side ditch by swing function of boom.
Close the bucket working device to the machine
body.
Slowly push away the soil from the side face of
soil pile.
If the soil pile is low, push the soil from the top.
If the load is too heavy for the machine body, lift
or lower the bulldozing blade for adjustment.
