SM – 100 Operation Manual
15
48 Setting of Scale Numbe
r

Enter value from range 0 to 999 999
49
T
ype of Client / Server Interface

0 No Interface 3 Not Used Related SPECs for Ethernet
I/F are SPEC50, 135, 214.
1 Ethernet (Coaxial Cable) 4 4-Lines (RS-485)
2 Ethernet (Twisted Pairs)
50 Setting of Client / Serve
r

0 Client 2 Backup Serve
r
Related SPECs for S/C
setting are SPEC61, 150, 163,
165, 187, 194, 208, 229, 252,
253, 254, 255, 265, 276.
1 Server / Workstation
51 Baud Rate of SIO (RS-232C Port)

0 1 200 bps 4 19 200 bps
A
pply to both RS-232C and
RS-485 ports setting for SM-
300.
Related SPECs are SPEC48,
52, 53, 54, 60, 134.
1 2 400 bps 5 38 400 bps
2 4 800 bps 6 76 800 bps
3 9 600 bps
52 Data Length of SIO (RS-232C Port)

0 7 Bits 1 8 Bits
A
pply to both RS-232C and
RS-485 ports setting for SM-
300.
53 Parity Bit of SIO (RS-232C Port)

0 None 2 Even
A
pply to both RS-232C and
RS-485 ports setting for SM-
300.
1 Odd
54 Stop Bit of SIO (RS-232C Port)

0 1 Bit 1 2 Bits
A
pply to both RS-232C and
RS-485 ports setting for SM-
300.
55 Baud Rate of Multi-drop SIO (RS-485 / 4-Lines Port)

0 1 200 bos 3 9 600 bps Related SPECS are SPEC48,
56, 57, 58, 59, 134.
1 2 400 bps 4 19 200 bps
2 4 800 bps 5 38 400 bps
56 Data Length of Multi-drop SIO (RS-485 / 4-Lines Port)

0 7 Bits 1 8 Bits
57 Parity Bit of Multi-drop SIO (RS-485 / 4-Lines Port)

0 None 2 Even
1 Odd
58 Stop Bit of Multi-drop SIO (RS-485 / 4-Lines Port)

0 1 Bit 1 2 Bits
59 Multi-drop SIO (RS-485 / 4-Lines Port) Select Job

0 No Operation 2 Pick ‘N’ Pay #2 #1 Either SPEC59 or 60 can
be selected at any one time.
#2 For SF only.
1 FIS 3000 #1
