Meter Engineers Handbook for Cellular Communication 10
4.2 Elster A3 Meters
Requires optional RS-485 communications board.
RJ-11 Connections
Black Receive -
Red Receive +
Green Transmit +
Yellow Transmit -
Modbus Communications Option document. IL42-4009D. Pgs. 2, 3
