4G Industrial VPN Quick Guide

Ethernet Port

TherearetwoEthernetportsin4GIndustrialVPNrouter,ETH1istheLANinterfaceandETH0canbetheLANorWANinterface.

TheEth0factorydefaultisasLANinterface.

Each Ethernet port has two LED indicators. The yellow one is Link indicator and the green one doesn’t mean anything.

TherearethreestatusofLinkindicator.Pleaserefertothetablebelow.

6 INDICATOR STATUS DESCRIPTION

Link Indicator Off Connectionisdown

  On Connectionisup

  Blink Dataisbeingtransmitted

Ground the Router

Groundingandwiringtherouterhelpslimitingtheeffectsofnoiseduetoelectromagneticinterference(EMI).

We suggest to connect the ground connector to a well-grounded mounting surface such as a metal panel.

Power Supply

7 Thepowersupplyrangeis9to26VDC.

Note: Please take care about the polarity, and do not make reverse connection.
