Chapter 3: Magma 13-Slot Expansion Chassis 13
Example 1, Magma 13-Slot
Pro Tools 24 MIX/MIXplus System
Power Macintosh G3, G4, or 9500/9600
Example 2, Magma 13-Slot
Pro Tools 24 System
Power Macintosh G3, G4, or 9500/9600
Chassis cards with multiple audio interfaces:
Slot Card
Exp. Slot Chassis Controller Card
Slot 1 MIX Core (Interface #1 and #2)
Slot 2 MIX Farm (interface #3 and #4)
Slot 3 d24 (Interface #5 and #6)
Slot 4 MIX I/O (Interface #7 and #8)
Slot 5 DSP Farm (Interface #9)
Slot 6 DSP Farm or SampleCell card
Slot 7 DSP Farm or SampleCell card
Slot 8 DSP Farm or SampleCell card
Slot 9 DSP Farm or SampleCell card
Slot 10 DSP Farm or SampleCell card
Slot 11 Available for non-bus master card
Slot 12 Available for non-bus master card
Slot 13 Available for non-bus master card
Beige G3 and 9500/9600 are only sup-
ported with Magma model PCI-13-RX-
400V (serial number PE01732 or higher).
Chassis cards with multiple audio interfaces:
Slot Card
Exp. Slot Chassis Controller Card
Slot 1 d24 (Interface #1 and #2)
Slot 2 d24 (Interface #3 and #4)
Slot 3 DSP Farm (Interface #5)
Slot 4 DSP Farm (Interface #6)
Slot 5 DSP Farm (Interface #7)
Slot 6 DSP Farm (Interface #8)
Slot 7 DSP Farm (Interface #9)
Slot 8 DSP Farm or SampleCell card
Slot 9 DSP Farm or SampleCell card
Slot 10 DSP Farm or SampleCell card
Slot 11 Available for non-bus master card
Slot 12 Available for non-bus master card
Slot 13 Available for non-bus master card
Beige G3 and 9500/9600 only supported
with Magma model PCI-13-RX-400V (se-
rial number PE01732 or higher).
