Digisol DG-GS4628FSE2 User Manual

DG-GS4600SE2 Installation Guide
Chapter 1-7
Table 1- 5 Port LEDs
LED
Status
Description
Green
On
On means ports are in the link state
of 10G, 1000M, 100M, 10M
Off
Off means ports are not in the link
state of 10G, 1000M, 100M, 10M
Blink
Send or receive the data
The other is system LEDs, they are used to show the work status of the system at
the right of front panel.
Table 1- 6 DG-GS4600SE2 System LEDs
Panel
Symbol
Status
Description
PWR1
On (Green)
Power1 is operating normally
Off
Power1 is not operating
DIAG
On (Green, blink)
System is loading
On (Green)
System is operating normally
PWR2
On (Green)
Power2 is operating normally
Off
Power2 is not operating
1.4.4 Interface Description of Front Panel
DG-GS4600SE2 series switches provide RJ-45 1000Mb copper port, interface of
SFP+ 10Gb fiber transceivers and combo interface.
Table 1- 7 interface descriptions
Interface mode
Spec
RJ-45 port
 10/100/1000Mbps auto negotiation
 MDI/MDI-X cable mode auto negotiation
 5 kinds of UTP: 100 m

Digisol DG-GS4628FSE2 Specifications

General

Brand	Digisol
Model	DG-GS4628FSE2
Category	Switch
Language	English
