DIGISYNTHETIC DS216A - Technical Specifications

Input
Impedance
CMRR >50dB 30Hz~20KHz
Output
Impedance
Maxim output electrical level Vpp=4V Vpp=7.6V
Frequency Resp. 20Hz~20.0kHz
Dynamic Range
Distortion 0.01%(THD)
Mixman Delay
Output gain -40dB~+6dB 0.5dB
Input gain
Parametric Equalizer
Filter
Gain 12
Central Freq. 20Hz~20kHz 31 ISO
Q value 0.5~10
Shelving
Lo-shelf 20Hz~1kHz
10K
50
7ms
-40dB~+6dB 0.5dB
dB in 1dB steps
Hi-shelf 1kHz~20kHz
Shelf gain 12dB in 1dB steps
HPF&LPF
Filter
Frequency (high pass) 10Hz~16.0kHz
Frequency (low pass) 35Hz~22.0kHz
Response curve Butterworth 6dB 12dB 18dB 24dB 48dB
Bessel 12dB 18dB 24dB 48dB
Linkwitz-Riley 24dB 48dB
Limiter
Level -20~+15dB
Attach time 1~100ms
Holding time 0~100ms
Decay time 10~1000ms
LCD 2 20
Input LED -30dB,-24dB,-12dB,-6dB,-3dB,Limit,Clip
Output LED -30dB,-24dB,-12dB,-6dB,-3dB,Limit,Clip
Connectors
Input XLR-3F
Output XLR-3M
Rs232
Power -220V/AC 50Hz, 110V/AC 50Hz
Weight 3.6KG
Size 480mm 44mm 220mm
