Wake up time
Fade-in Volume rise to memory mode slowly.
Mute hold all channels are mute.
Delay Time/distance Delay unit display.
Time(ms
Metres
Feets
4 Interface submenu
Interface submenu include RS232 baud rate and address code setting. Select 2400
4800 9600 19200 38400 baud rate according different PC.
Remote ID NUM 1~32
5 Parameter
Push ain to enter setup menu push Back Next to switch menu rotate
Param to adjust parameter.
A Input gain Input A Ipput B Gain adjust range is 40.0dB~+6.0dB 0.5dB.
B Output gain Op1 Op6.
C Output phase Polanty [+] [-].
D Delay adjustment range is 0ms~7ms -0.5ms.
Input A Gain
Gain=0.0dB
Op1 low Gain
Gain=0.0dB
Op1 low Gain
Polarity=[+]
Op1 LOW Delay
Delay=0.0ms
OPERATION
