DVM-500 User’s Guide Digital In-Car Video System
Digital Ally DVM User Guide Rev. F (334/1.6.2) Page 19 of 36
Monitor Menu
ON/OFF/AUTO
This setting controls whether the built-in monitor is on or off when in
Operating Mode. When set to ON, the monitor will always be on.
When set to OFF, the monitor will always be off. When set to Auto, it
will turn on automatically when recording. (This setting also applies to
the output for the external monitor if enabled.)
While recording, the monitor can be toggled off and on by briefly
pressing the MENU/6 Button.
Brightness
The brightness of the internal LCD monitor can be adjusted with this
setting (1 is the dimmest setting and 9 is the brightest setting).
Internal/External Display
When EXT is selected, external output is turned on and internal
monitor is disabled.
Important: If EXT is selected by accident, and an external
display is not connected to the DVM, then the built-in display can
be turned back on by pressing the MENU/6 button when the
Digital Ally splash screen is displayed during system startup.
Backlight Menu
Backlight
This setting controls the brightness of the backlit buttons on the front
of the DVM (0 turns off backlighting and 9 backlights all buttons at the
brightest level of illumination).
Rear Status LEDs
Turns ON/OFF the status lights on the back of the DVM:
Red (indicates that the DVM is recording)
Green (indicates that the RMT audio is being recorded)
Menu Item Settings Default
ON/OFF/AUTO ON, OFF, AUTO ON
Brightness 1 to 9 8
Internal/External Display INT, EXT INT
Backlight 0 to 9 5
Rear Status LEDs ON, OFF ON
