3. Configuring communications on the HD-
IP470
The HD-IP470 supports communications over wired LAN and Cellular.
Connecting over a 3G/4G cellular network
A valid mobile SIM card is required in order to connect the HD-IP470 over a cellular communications
bearer. The unit has an inbuilt modem for 3G/4G connection with 3G/4G antenna connectors on the side
of the device. Note: despite the ultra-efficient bandwidth usage achieved by TVI, the HD-IP470 is
considered a heavy data use product on cellular networks. It is recommended that an unlimited data plan
(or if unavailable, a heavy consumption data plan) is set up with your Mobile Network Service Provider for
use with the HD-IP470.
The SIM card holder is located inside the unit under the modem card – this supports a standard size SIM
card. To install micro or nano size cards an adaptor will be required.
Before installing the SIM card:
 The unit should be disconnected from the power supply when installing the SIM
card.
 Take precautions to prevent static discharge when handling components.
To install the SIM card carefully follow these steps:
3.1.1 Remove the hatch
Unscrew and safely store the four black bolts holding the base hatch in place. Then remove the hatch.
