Digital Projection E-Vision Laser 8500 Series Important Information

Digital Projection E-Vision Laser 7500 & 8500 Series
Rev D January 2017
Page 5
Important Information
Electrical and physical specications
Main Voltage 200-240 VAC 4.5A 50/60Hz
100-130 VAC 9.5A 50/60Hz
Operating Temperature 0°C to 40°C
Storage Temperature -20°C to 60°C
Operating Humidity 20% to 90% non-condensing
Weight 28 kg (61.7 lb) without lens
Power Consumption 8500 Series 7500 Series
at 100 Vac: 920 W 820 W
at 240 Vac: 880 W 630 W
Thermal Dissipation 8500 Series 7500 Series
at 100 Vac: 3137 BTU/hr 2796 BTU/hr
at 240 Vac 3000 BTU/hr 2148 BTU/hr
Laser precautions
CLASS 3R LASER PRODUCT
This Laser Product is designated as Class 3R during all procedures of operation.
LASER LIGHT - AVOID DIRECT EYE EXPOSURE.
Do not point laser or allow laser light to be directed or reected toward other people or
reective objects.
Direct or scattered light can be hazardous to eyes and skin.
There is a potential hazard of eye exposure to laser radiation if the included
instructions are not followed.
Caution – use of controls or adjustments or performance of procedures other than
those specied herein may result in hazardous radiation exposure.
Laser Parameters:
Wavelength 450nm - 460nm (Blue)
Mode of operation Pulsed, due to frame rate
Pulse width 0.74ms
Pulse repetition rate 240Hz
Maximum laser energy 0.376mJ
Total internal power >100W
Apparent source size >10mm, at lens stop
Divergence >100 mili Radian
