RS232 Connecons
Analog Audio Connecons
USB Connecons
IR Connecons
To use the RS232 control transport capabilies of the IPEXCB or the RS232 extension capabilies of the encoders
and decoders, connect the TX, RX, and ground control signal wires to the removable 3-pole terminal block. Consult
the manual of the source or display device(s) to determine which pins the TX and RX signals are carried on. Be sure
to always connect TX to RX and RX to TX.
The analog audio input and output connecons on the IPEX5001 / IPEX5001-D and the analog audio output
connecons on the IPEX5002 use standard 3.5 mm TRS connectors.
Note: Two channel audio in/out capability is only achieved when using the 2CH Stereo EDID seng in the Digitalinx
IP Congurator soware under EDID SETTINGS. Please see the Digitalinx IP Deployment Guide for conguring this
funconality.
The IPEX5000 system is USB 2.0 Full Speed compliant up to 12Mbps
The USB Host port on the IPEX5001 / IPEX5001-D / IPEX5001-WP-W is provided to allow control of a PC source
from a remote locaon. The USB Device ports on the IPEX5002 are provided to add keyboard, mouse or interacve
white board control for the host PC connected to the routed encoder.
The USB signal from the decoder to the encoder follows the video route by default however this can be free routed
using the DigitalinxIP API. See DigitalinxIP Programming Guide online at libav.com
The IR connecons on the IPEX5000 encoders and IPEX5002 provide a means to control remote IR equipment. The
IR signals between the IPEX5000 encoders and IPEX5002 follow the video route however IR can be free routed via
API. See DigitalinxIP Programming Guide online at libav.com
Please ensure power is disconnected from the encoders and decoders before connecng the IR receiver to the IR
input ports on the devices.
TX
G
RX
RXD
TXD
GND
IPEX5001 or
IPEX5002
Source or
Display
IPEX5001 / IPEX5001-D
IPEX5002
IPEX5001-WP-W
