DigitaLinx IPEX5001-D - IPEX5002 Technical Specifications

IPEX5000 Series Quick Install Guide
19
IPEX5002 Technical Specicaons
Input/Output Connecons
HDMI Input One (1) HDMI Type A Receptacle
HDMI Output One (1) HDMI Type A Receptacle
LAN One (1) 8P8C port (Shielded RJ45)
Power One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel
RS232 Port One (1) 3-pin Removable Terminal Block Connector
USB Device Two (2) USB Type A Port
Audio Output One (1) 3.5 mm TRS Receptacle
IR Input One (1) 3.5 mm TRS Receptacle
IR Output One (1) 3.5 mm TRS Receptacle
Reset One (1) Momentary Push Buon
Mode One (1) Two Posion Slider Switch
DIP One (1) Four Posion DIP Switch
Supported Audio, Video and Control
Video Resoluons SMPTE: 480p, 576p, 720p, 1080i, 1080p, 2160p/30 (4:4:4)
VESA: Resoluons up to 1920x1200
Color Depth: 24, 30, 36 bit
Video Compliance HDMI 1.4/2.0 and HDCP 1.4/2.2
Embedded Audio Up to PCM 8 channel, Dolby Digital True HD, DTS-HD Master Audio and Dolby Atmos and
DTS-X
ARC (Audio Return Channel) No
HEC (HDMI Ethernet Channel) No
CEC (Consumer Electronics Control) Yes
Supported Baud Rates 2400, 4800, 9600, 19200, 38400, 57600, 115200
USB Compliance USB 2.0 Full Speed up to 12Mbps
Streaming Signal Characteriscs
Maximum Distance (point to point) 100 m (328 )
Cable Requirements Category 5e or greater with TIA/EIA-568B crimp paern
Encoded Data Rate 2160p: Average; 250 Mbps
1080p: Average; 150 Mbps
Encoded Method VBR
End to End Latency 17-33 ms (1-2 fps)
Maximum Video Wall Size 16x16
Chassis and Environmental
Construcon Black Steel
Dimensions (H x W x D) 25 mm x 220 mm x 130.2 mm (0.98in x 8.66 in x 5.13 in)
Operang Temperature 0° to +40° C (+32° to +104° F)
Operang Humidity 20% to 90%, Non-condensing
Storage Temperature -10° to +60° C (+14° to +140° F)
Storage Humidity 20% to 90%, Non-condensing
Power and Regulatory
Power Input 12V DC 1A or 48V DC PoE (Power over Ethernet)
Power over Ethernet (PoE) Compability 802.3af Alternave B
Power Consumpon 6 was
ESD Protecon 8kV air, 4kV contact
Regulatory FCC, CE, RoHS
Other
Warranty 5 years
Diagnosc Indicators Power and Status
Included Accessories Installaon Guide, Power Supply, 3-pin Removable Screw Terminal, Mounng Ears (2 ea), IR
emier, IR receiver
IP Controller IPEXCB
Compable Encoder IPEX5001
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and electrical interference, and cable
patches.
