DigitaLinx IPEX5001-D - IPEX5002 Decoder

IPEX5000 Series Quick Install Guide
6
The Digitalinx IP IPEX5002 receives HDMI video and audio over a 1 gigabit network infrastructure using JPEG2000
encoding from the IPEX5001 and IPEX5001-WP-W encoder. The IPEX5002 outputs video signals navely from
source or can be scaled to 1080p or 4K at 24/30Hz 4:4:4 with HDR10, HDCP 2.2 and mulchannel audio support.
An analog audio output port de-embeds stereo 2 channel audio from the HDMI content while sll passing stereo 2
channel audio to the HDMI output. Depending on the needs of the installaon, mulple IPEX5002 devices can be
congured to make a video wall up to a 16x16 conguraon.
The IPEX5002 supports PoE power and can be powered remotely via PoE network switch eliminang the need for a
nearby power outlet. The RS232 port relays commands from the IPEXCB controller and operates in a pass through
mode to control a third party device such as a TV display or HDMI switcher. The USB client port connecons is for
connecng USB client devices such as an interacve white board or HID devices that is USB 2.0 Full Speed compliant
up to 12Mbps that can communicate with the host device connected to an encoder. USB roung follows the video
route by default however USB communicaon can be free routed via API. The IPEX5001 features bi-direconal IR
support which follows the video route or can be routed freely via API command.
The IPEX5002 requires a single IPEX5001 for a point to point installaon. When mulple IPEX50012
and/or IPEX5001 devices are in a system, an IPEXCB control box will be required.
IPEX5002 Decoder
The Digitalinx IP IPEX5001-D transmits HDMI video and audio over a 1 gigabit network infrastructure using JPEG2000
encoding with a variable data rate at an average of 250 Mbps with peak values up to 850Mbps. The IPEX5001-D
is Dante enabled meaning that the encoder can on ramp two channel stereo audio either from the embedded
HDMI audio stream or the analog audio 3.5mm input onto a Dante audio network. The mulcast video and Dante
audio IP streams are integrated into one Ethernet cable simplifying networked audio and video soluon into one.
An analog audio output port de-embeds stereo 2 channel audio from the HDMI two channel stereo embedded
stream, while sll passing stereo 2 channel audio to the HDMI output. The IPEX5001-D supports video signals up to
4K at 60 Hz 4:2:0 / 8 bit deep color, 4K at 24Hz 4:2:0 / 10 bit deep color for HDR10 support and HDCP 2.2 support.
The IPEX5001-D supports PoE power and can be powered remotely via PoE network switch eliminang the need
for a nearby power outlet. The RS232 port relays commands from the IPEXCB controller and operates in a pass
through mode to control a third party device such as a TV display or HDMI switcher. The USB host port connecon
is for connecng USB host devices such as a computer that is USB 2.0 Full Speed compliant up to 12Mbps that can
communicate with client side devices connected to the decoder. USB roung follows the video route by default
however USB communicaon can be free routed via API.
IPEX5001-D Encoder
