IPEX5000 Series Quick Install Guide
17
IPEX5001-WP-W Technical Specicaons
Input/Output Connecons
Video Input One (1) HDMI (Type A Receptacle), One (1) VGA (DB-15)
LAN One (1) 8P8C port (Shielded RJ45)
Power One (1) 2 pin phoenix connector
RS232 Port One (1) 3.5mm
USB Device One (1) USB Type B Port
Audio Input (VGA) One (1) 3.5 mm TRS Receptacle
Reset One (1) Momentary Push Buon
Supported Audio, Video and Control
Video Resoluons SMPTE: 480p, 576p, 720p, 1080i, 1080p, 2160p/30 (4:4:4), 2160p/60 (4:2:0)
VESA: Resoluons up to 1920x1200
Color Depth: 24, 30, 36 bit
Video Compliance HDMI 1.4 and HDCP 1.4/2.2
Embedded Audio Up to PCM 8 channel, Dolby Digital True HD, DTS-HD Master Audio, Dolby Atmos and DTS-X
ARC (Audio Return Channel) No
HEC (HDMI Ethernet Channel) No
CEC (Consumer Electronics Control) No
Supported Baud Rates 2400, 4800, 9600, 19200, 38400, 57600, 115200
USB Compliance USB 2.0 Full Speed up to 12Mbps
Streaming Signal Characteriscs
Maximum Distance (point to point) 100 m (328 )
Cable Requirements Category 5e or greater with TIA/EIA-568B crimp paern
Encoding Data Rate 2160p: Average; 250 Mbps
1080p: Average; 150 Mbps
Encoding Method VBR
End to End Latency 17-33 ms (1-2 fps)
Chassis and Environmental
Dimensions (H x W x D) 105.6 mm x 89 mm x 43.5 mm (4.1in x 3.5 in x 1.7 in)
Operang Temperature 0° to +40° C (+32° to +104° F)
Operang Humidity 20% to 90%, Non-condensing
Storage Temperature -10° to +60° C (+14° to +140° F)
Storage Humidity 20% to 90%, Non-condensing
Power and Regulatory
Power Input 12V DC 1A or 48V DC PoE (Power over Ethernet)
Power over Ethernet (PoE) Compability 802.3af Alternave A
Power Consumpon 6 was
ESD Protecon 8kV air, 4kV contact
Regulatory FCC, CE, RoHS
Other
Warranty 5 years
Diagnosc Indicators Power and Status
Included Accessories Installaon Guide, (1) 2 pin phoenix connector, (1) 2 gang decora wall plate cover with screws,
(4) mounng screws
IP Controller IPEXCB
Compable Decoder IPEX5002
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and electrical interference, and cable
patches.
