Digitax F2 PLUS User Manual

The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third
party is strictly prohibited.
38
214
The taxi-light must go ON in overspeed? - If Yes then the taxi-light will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
215
Taxi-light must go on overspeed?
No / Yes
from Q 216 / available for any possible software extension / to Q 218
219
Taxi-light ON in this tariff-block? - With Yes the taxi-light will go ON in the corrisponding tariff-block.
The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
220
Block-number for taxi-light to be ON: this is the number of the tariff-block where the taxi-light should be ON. The allowed value goes from 0 (min) to 62 (max).
0 - 62
221
Prog-Date-number for taxi-light to be ON: this is the number of the Prog-Date where the taxi-light should be ON. The allowed value goes from 0 (min) to 8 (max).
0 - 8
222
State of taximeter for taxi-light to be ON - This is the state (or states) of the taximeter in which the taxi-light should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON the taxi-light in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
For Hire = 128
Stopped = 64
Hired = 32
None = 0
LIGHT N. 1
223
Enable light n. 1 ON in day-time? - Should it be possible for light number 1 to be ON during the day-time?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
224
Light n. 1 must flash? - If Yes light number 1 will flash. The allowed answer is either: 0 (No: no flash) or: 1 (Yes: flash).
No / Yes
225
Light n. 1 must go ON in overspeed? - If Yes then light number 1 will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
226
Light n. 1 must go on below overspeed?
No / Yes
227
The light n.1 is used a Buzzer output ? If Yes then the light N.1 will go ON for a short time in case a buzzer beep is programmed (Q338, Q339, Q340)
No / Yes
228
The Light n.1 must go ON if the shift is Open? If Yes then the Light n.1 will go ON in case the shift is OPEN
No / Yes
229
Available for future extensions
No / Yes
230
Light n. 1 ON in this tariff-block? - With Yes light number 1 will go ON in the corrisponding tariff-block.
The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
231
Block-number for light n. 1 ON: this is the number of the tariff-block where light number 1 should be ON.
The allowed value goes from 0 (min) to 62 (max).
0 - 64
232
Prog-Date-number for light n. 1 ON: this is the number of the Prog-Date where light number 1 should be ON.
The allowed value goes from 0 (min) to 8 (max).
0 - 8
233
State of taximeter for light n. 1 ON: this is the state (or states) of the taximeter in which the light number 1 should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON light number 1 in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
For Hire = 128
Stopped = 64
Hired = 32
None = 0
LIGHT N. 2
234
Enable light n. 2 ON in day-time? Should it be possible for light number 2 to be ON during the day-time?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
235
Light n. 2 must flash? - If Yes light number 2 will flash. The allowed answer is either: 0 (No: no flash) or: 1 (Yes: flash).
No / Yes
236
Light n. 2 must go ON in overspeed? - If Yes then light number 2 will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
237
Light n. 2 must go on below overpseed?
No / Yes
238
The light n.2 is used a Buzzer output ? If Yes then the light N.2 will go ON for a short time in case a buzzer beep is programmed (Q338, Q339, Q340)
No / Yes
239
The Light n.2 must go ON if the shift is Open? If Yes then the Light n.2 will go ON in case the shift is OPEN
No / Yes
240
Available for future extensions
No / Yes
241
Light n. 2 ON in this tariff-block? - With Yes light number 2 will go ON in the corrisponding tariff-block. The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
242
Block-number for light n. 2 ON: this is the number of the tariff-block where light number 2 should be ON. The allowed value goes from 0 (min) to 62 (max).
0 - 62
243
Prog-Date-number for light n. 2 ON: this is the number of the Prog-Date where light number 2 should be ON. The allowed value goes from 0 (min) to 8 (max).
0 - 8
244
State of taximeter for light n. 2 ON: this is the state (or states) of the taximeter in which the light number 2 should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON light number 2 in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
For Hire = 128
Stopped = 64
Hired = 32
None= 0
LIGHT N. 3
245
Enable light n. 3 ON in day-time? - Should it be possible for light number 3 to be ON during the day-time?
No / Yes
