Digitax F2 PLUS User Manual

The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confidential. Any disclosure, copying, distribution to third party
is strictly prohibited.
39
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
246
Light n. 3 must flash? - If Yes light number 3 will flash. The allowed answer is either: 0 (No: no flash) or: 1 (Yes: flash).
No / Yes
247
Light n. 3 must go ON in overspeed? - If Yes then light number 3 will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
248
Light n. 3 must go on below overspeed?
No / Yes
249
The light n.3 is used a Buzzer output ? If Yes then the light N.3 will go ON for a short time in case a buzzer beep is programmed (Q338, Q339, Q340)
No / Yes
250
The Light n.3 must go ON if the shift is Open? If Yes then the Light n.3 will go ON in case the shift is OPEN
No / Yes
251
Available for future extensions
No / Yes
252
Light n. 3 ON in this tariff-block? - With Yes light number 3 will go ON in the corrisponding tariff-block. The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
253
Block-number for light n. 3 ON: this is the number of the tariff-block where light number 3 should be ON. The allowed value goes from 0 (min) to 62 (max).
0 - 62
254
Prog-Date-number for light n. 3 ON: this is the number of the Prog-Date where light number 3 should be ON. The allowed value goes from 0 (min) to 8 (max).
0 - 8
255
State of taximeter for light n. 3 ON: this is the state (or states) of the taximeter in which the light number 3 should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON light number 3 in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
For Hire = 128
Stopped = 64
Hired = 32
None= 0
LIGHT N. 4
256
Enable light n. 4 ON in day-time? - Should it be possible for light number 4 to be ON during the day-time?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
257
Light n. 4 must flash? - If Yes light number 4 will flash. The allowed answer is either: 0 (No: no flash) or: 1 (Yes: flash).
No / Yes
258
Light n. 4 must go ON in overspeed? - If Yes then light number 4 will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
259
Light n. 4 must go on below overspeed?
No / Yes
260
The light n.4 is used a Buzzer output ? If Yes then the light N.4 will go ON for a short time in case a buzzer beep is programmed (Q338, Q339, Q340)
No / Yes
261
The Light n.4 must go ON if the shift is Open? If Yes then the Light n.4 will go ON in case the shift is OPEN
No / Yes
262
Available for future extensions
No / Yes
263
Light n. 4 ON in this tariff-block? - With Yes light number 4 will go ON in the corrisponding tariff-block. The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
264
Block-number for light n. 4 ON: this is the number of the tariff-block where light number 4 should be ON. The allowed value goes from 0 (min) to 62 (max).
0 - 62
265
Prog-Date-number for light n. 4 ON: this is the number of the Prog-Date where light number 4 should be ON. The allowed value goes from 0 (min) to 8 (max).
0 - 8
266
State of taximeter for light n. 4 ON: this is the state (or states) of the taximeter in which the light number 4 should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON light number 4 in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
ForHire= 128
Stopped= 64
Hired= 32
None= 0
VARIOUS FUNCTION
267
Available for future extensions
No / Yes
268
Disable visualization of clock on display? - Should the visualization of the clock on the (secondary) display be disabled?
The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
269
Inhibit clock-time programming from panel? - Should the possibility to program the clock-time from the panel be inhibited?
The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
270
Disable visualization of chronometer? - Should the visualization of the chronometer on the display be disabled?
The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
271
In ForHire show text "F-HIRE" on display? - Should the text "F-HIRE" be shown on the primary display when in ForHire?
The allowed answer is either: 0 (No: show text) or: 1 (Yes: don't show text).
No / Yes
272
Distance is in yards ? (if not: metres) - The distance in Q.2 to Q.4 is in yards? If not then the distance is in metres.
The allowed answer is either: 0 (No: metres) or: 1 (Yes: yards).
0=metres
1=yard
273
Show the decimal point as cents when showing money? Should the decimal point between the second and third position (from the right) be ON showing money?
The allowed answer is either: 0 (No: put OFF) or: 1 (Yes: put ON, for example 5.00).
No / Yes
274
Show the decimal point as mills when showing money? Should the decimal point between the third and fourth position (from the right) be put ON showing money?
The allowed answer is either: 0 (No: put OFF) or: 1 (Yes: put ON, for example 5.000).
No / Yes
275
From Stopped back to Hired with key K2? - Should it be possible to go from Hired to Stopped pressing key K2?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
