Digitax F3 Plus - K Constant Calibration; Calculating the K-Constant (Autotest); Inserting the K-Constant Value


TheinformationcontainedherearepropertyofDIGITAXAutomotiveElectronicsItaly,andextremelyconfidential.Anydisclosure,copying,distributiontothird
partyisstrictlyprohibited.

12
“K”Constant
(CarTransmissionRatio)
The“KConstant”isthenumberofpulsesperKilometeremittedbyatransducerandreceivedbyataximeter.
KConstant=Pulses/Kilometer
Thepulsescanbeemittedbythecar’selectronictransduceror,ifthecarisnotprovideofit,bytheDigitax
mechanicalone.Thisconstantcanbe
knowedorbetestedonroad.
HowtofindouttheK‐Constantvalue(Autotest)
Followthisproceduretofindoutthecartansmissionratio(K‐constant).
Forarightprocedureitmustbedoneinaroadwithacarefullymarkeddistanceof1Kilometer(default).

Aligncarefullythecar’sfrontwheelswiththetestdistance‘sstartline





SelectForHireposition.
PressK2andK3buttonsatthesametime.
Thefaredisplayshows“Attest”forafewsecondsandthenthe
“ForHire‐Stopped‐Hired”signslightontogether.

Now start driving thetest distance (1 kilometer) at 30 Km/Hour
maximum.

Reachthefinishline,previously
marked,andstopthecar:
the extras display will show the number of pulses emitted during the
test‐distancerun.

Keep note of this value. The aim of it is to calibrate the taximeter to
calculatetheK‐constant.

PressOPbuttontoendtheprocedureandgobackto
ForHireposition.
Takeoutthetaximeterprogrammingcover
SelectForHireposition.
InserttheBlackProgrammingKeyinitsslot.
PressK2andK3buttonsatthesametime.
Thebigdisplayshows“Attest”forafewseconds.

The“ForHire‐Stopped‐Hired”signslightontogether.
Thefare
displayshowstheprogrammedK‐Constantvalue.
TheextrasdisplayshowsthemeterstobecoveredfortheAutotest

PressK2buttontoincreasethepulses/kmnumber.




PressK1buttontodecreasethepulses/kmnumber.


Referringtotheaboveexample,pressK1buttontilltoreach680value

(pulsesfindedoutintheautotest)showedinthefaredisplay.


PressOPbuttontoendtheprocedureandgobacktoForHireposition.
TakeouttheBlackProgrammingKeyfromthetaximeter.
Autotest StartingPoint
AutotestFinishingPoint
1KilometeratMax30Km
/
Hour.
Meters
HowtoinserttheK‐Constantvalue
FollowthisproceduretocalibratethetaximeterwithaknowK‐Constant value.
