The microphone uses a miniature 6 pin style plug and socket.
To connect the microphone:
1. Push the MIC plug at the end of the
microphone cord into the MIC jack
until the connection locks into place.
Gently tug the MIC cord to test
that the connection is locked.
2. Use the MIC Jack cover which
is threaded onto the MIC cord
to seal the MIC jack entry from
dust.
The cradle can be screwed or bolted in any convenient location in your vehicle
(under or above the dash, on the centre console, etc) using the mounting slots
provided in the base.
For maximum sound output from the build in speaker, we recommend the
cradle be mounted above the radio to minimize any obstruction of the speaker.
Avoid mounting close to heaters or air conditioners. Screw the mounting cradle
to a firm surface and put the radio into the cradle from the front until it clicks
into place.
Finally, connect the power cord and antenna cable to the sockets provided at
the rear of the radio.
