Specifications
Controls: Mode Button, Tuning Button, On/Off Pedal
Jacks: Input, Mute, Thru
Input Impedance: >1 MΩ - tuner on
Input Impedance: True hardwire bypass - tuner off
Power Supply: 9 V Alkaline Dry Battery or Harman power supply
Current Draw: 40 mA (typical at 9 VDC)
Power Consumption: 365 mW (typical w/optional power supply)
Dimensions: 5.25”(L) x 3.5”(W) x 2.15”(H)
Weight: 1.3 lbs.
Optional Power Supply: Country (Voltage) Compatible PSU Models
Japan (100 VAC, 50/60 Hz): PS200R-100 or PS0913DC-01*
US and Canada (120 VAC, 60 Hz): PS200R-120 or PS0913DC-01*
Europe (230 VAC, 50 Hz): PS200R-230 or PS0913DC-01*
UK (240 VAC, 50 Hz): PS200R-240 or PS0913DC-02*
Australia (240 VAC, 50 Hz): PS200R-240-AU or PS0913DC-02*
Power Supply Polarity:
Power Supply Output: PS200R (9.6 VDC 300 mA), PS0913DC* (9 VDC 1.3 A)
*Recommended power saving GreenEdge power supply models.
