Entering the PEDAL STATUS number: is done by switching the MODE SWITCH to the PEDAL STA-
TUS position. Depress the right foot switch, advancing the PEDAL STATUS number to the desired value.
This is usually the last value selected, so it is usually appropriate to store the selected values at this paint
by depressing the left foot switch.
The continuous controller pedal transmits data to the function selected by the PEDAL STATUS
number. The position of the 0 to +5 volt controller pedal determines what data is sent and indirectly
what eect is controlled in what manner.
IMPORTANT NOTES: Care must be taken when using the continuous controller and changing to an-
other preset without the same continuous controller denition. The last state which the continuous
controller transmits to the eect will remain when you change presets. For example: if you were using
the controller pedal as a main volume control (PEDAL STATUS number 7), and you reduce the volume
to minimum then change to another preset in which the pedal is disabled, the main volume will remain
Midi No. Description
1 modulation wheel or lever
5 portamento time
7 main volume
10 pan controller
92 tremolo depth
93 chorus depth
95 phaser depth
Cp channel pressure
Pb pitch bend
Pd pedal disabled
