TUTORIAL: EXAMPLE PRESET PROGRAMMING
Let's take the following preset example as illustrated on the programming planning chart:
To enter this preset:
Place the MODE SWITCH in the PROGRAM position and the DATA SWITCH in the BANK/PRESET
position. Advance the BANK number with the left foot switch until the number "2" appears in the left
portion of the LED display and advance the PRESET number with the right foot switch until the number
"15" appears in the right side of the LED display.
Place the DATA SWITCH in the PROGRAM CHANGE position and advance the number with the
right foot switch until "23" appears in the LED display.
Place the DATA SWITCH in the MIDI CHANNEL position and advance the number with the right
foot switch until . 1" appears in the LED display.
Place the MODE SWITCH in the PEDAL STATUS position and advance the number with the right
foot switch until “1” appears in the LED display.
Depress the left foot switch to store the preset in memory. Four dashes - - - - appear in the LED dis-
play conrming that the preset is being stored.
To enter the END-OF-BANK marker:
After you have stored the preset as shown above, return MODE SWITCH to PROGRAM and the DA-
TA SWITCH to the BANK/PRESET position. Advance the PRESET number to number 16. The LED indi-
cator will show " 216" to indicate that you are now programming bank #2, preset #16.
Place the DATA SWITCH in the PROGRAM CHANGE position and advance through all 128 num-
bers and stop when the display reads "Eb."
Store the END-OF-BANK marker by depressing the left foot switch. Four dashes - - - - will appear on
the LED display indicating that the END-OF-BANK marker is being stored.
To recall and transmit the preset:
Place the MODE SWITCH in the OPERATE position and the DATA SWITCH in the BANK/PRESET
position. Depress the left foot switch until "2" appears in the left portion of the LED display and depress
BANK NUMBER PRESET NUMBER PROGRAM NUMBER CHANNEL NUMBER PEDAL STATUS COMMENTS
2 15 23 1 7 volume pedal
2 16 Eb - - end of bank marker
To Next Page
