Section Three - Models and Effects
About the Models
The RP70 can be thought of as several different “virtual” amplifiers and individual, high-tech
stompboxes in a single programmable package. With stompboxes, the order in which they are
connected affects the overall sound. The RP70 has placed the Amp and Effect models in an order
for optimum results. The following diagram shows the order in which they are connected.
Pickup/
Wah
Compressor EQ
Amp-Cabinet/Distortion
Modeling
Volume Pedal
(Pre)
Volume Pedal
(Post)
Chorus/FX
(Whammy)
Chorus/FX
Noise Gate
Delay Reverb
