3. Treadle - This Pedal is used to bend the input note, bend between harmony intervals, or mix
detuning with your input signal.
4. Effect Switch - This switch turns the effect on and off.
5. Input - Connect your instrument to this jack.
6. MIDI In - Connect any external MIDI device to this jack for the purpose of controlling the
Whammy™ remotely.
7. Power - Connect the provided power supply to this jack. Do not use any power supply
other than the supplied PS750 or PS0913B.
8. Dry Out - This jack contains your dry guitar signal only. No effect is present at this output.
9. Wet Added - This jack contains a mix of your dry guitar signal, and the pitch shifted signal
produced by the Whammy™.
