DigiTech WHAMMY - Operational Controls and Connections

Making Connections
The Whammy™ pedal is extremely easy to set up and use. Simply follow these steps and you be
Whammin.
1. Connect your instrument to the Whammy™ input.
2. Connect from the “Wet Added” output to your favorite distortion pedal or to your amplifier.
3. Connect from the Whammy™ Dry Out to a guitar tuner if desired.
4. Connect from the MIDI Out of a MIDI controller to the MIDI In on the Whammy™ if
desired.
5. Connect the power supply between an AC outlet and the power jack on the Whammy™.
6. Turn on you amp and adjust the volume to a desired level.
7. Rotate the Preset knob to select the desired effect or interval.

Distortion Pedal
Tuner
Dry Out
Wet Added
Input
AC Power
MIDI Out
MIDI In
