6
For the MDI-X port of a switch or hub, cross lines are used: 1-3, 2-6,
3-1, 6-2, 4-7, 5-8, 7-4, 8-5.10Base-T/100Base-T (X) pins are defined as
follows:
Pin No.
MDI signal
MDI-X signal
1
TX+
RX+
2
TX-
RX-
3
RX+
TX+
6
RX-
TX-
4,5,7,8
-
-
Note: "Tx ±" refers to send data, "Rx ±" refers to received data ±, and
"-" refers to unused data.
5.2 1000base-FX Ehernet interface
This device provides 1000Base single-mode dual-
fiber SC module, and multi-mode like LC, ST as optional.
5.2.1 Patch cord classification
According to the transmission mode of light in the fiber, it can be
divided into multi-mode fiber and single-mode fiber. Multimode fiber
has a thick glass core (50 or 62.5μm), which can transmit light in
various modes. However, the high inter-mode dispersion limits the
frequency at which digital signals can be transmitted, so multimode
fibers can be transmitted over relatively close distances (typically only
a few kilometers).
The single-mode fiber has a very thin glass core (core diameter, usually
9 or 10μm) and can transmit only one mode of light. Therefore, it’s
inter module dispersion is very small, and it is suitable for remote
communication. Under normal circumstances, the skin is orange for
multi-mode, yellow for single mode.
