4
Indicators PoE ready / in-use
Connectors
Shielded RJ-45, EIA 568A
and 568B
Operating Ambient
Temperature
-40 to 75°C
Operating Humidity
Maximum 90%,
non-condensing
Storage Temperature -40 to 75°C
Storage Humidity
Maximum 95%,
non-condensing
5 Product Outlook
Front Panel
The front panel composed by PSE output ports with data link
port, the relevant indicator, as shown below:
PoE In: connect to the PSE or PoE Injector with a UTP cable.
Data: Connect to the Ethernet device with CATS UTP cable to
transmit data.
DC Out: Connect to the power port of the Ethernet device
with the provided power cable to supply the power 12V DC.
