6. Interface Definition
6.1 10/100/1000Base-TX Ethernet interface:
This series of switches provides MDI/MDI-X self-identification with
cable support on all 10/100/1000Base-TX ports. In use, the Ethernet
port of the switch can be connected with other Ethernet terminal
devices through network cables (direct or cross). Please use Class 5
shielded twisted pair. The Ethernet port pin definition is shown in the
following figure:
