The following chart shows the LED indicators of the Switch along
with explanation of each indic ato r.
Indicator
Faceplate
Marker
Status Indication
PWR
Status Light
PWR
Off
Power Off.
Solid
green
Power On.
10/100/1000
BASE-adaptive
Ethernet
port indicator
Link/Act/
Speed
Off
Power Off.
Solid
green
Power On.
Solid
orange
The port is
connected at
100/10Mbps.
Blinking
The port is
transmitting or
receiving data.
SFP port
indicators
Link/Act
Off
The port is
NOT connected.
Solid
green
The port is
connected
Blinking
The port is
transmitting or
receiving data.
10/100/1000 Mbps RJ-45 ports (1~8):
Designed to connect to the device with a bandwidth of 10Mbps,
100Mbps, 1000Mbps. Each has a corresponding Link/Act/Speed
indicator.
