Digitus DN-80120 User Manual

5
5.1 Product Diagram
1
Broadband Router
6
Home Cinema
2
Wireless Access Point
7
IPTV
3
Laptop
8
Game Player
4
VoIP Phone
Network cable
5
IP Camera
Fiber cable
5.2 LED Indicator
LED
status
Description
PWR
on
Power Operating normally
off
PWR is not connected or is not
operating properly
Link
on
Port link UP
flash
Port forwarding data
off
Port link DOWN or not connect
10/100/1000
Base-T
(Gigabit switch)
on
1000Base-T
off 10/100Base-T

Digitus DN-80120 Specifications

General

Brand	Digitus
Model	DN-80120
Category	Switch
Language	English
