Features
• Compatible with IEEE802.3af and IEEE802.3at
• Extends the range of PoE and Ethernet an additional 100 meters
• No additional power supply is required
• Automatically detects and protects PoE equipments from being damaged by
incorrect installation
• Full-rate network throughout the whole extended distance
• Compact size, Wall-Mountable design
• Easy plug-and-play installation
• EMI standards complies with FCC, CE class B
Specifications
Item Description
No. of channels 1
Pass Through Data Rates 10/100/1000 Mbps half/full duplex
Power over Ethernet input Pin Assignment and Polarity:
Both 1/2 (-), 3/6 (+) and 7/8 (-), 4/5 (+)
Power over Ethernet Output Pin Assignment and Polarity:
1/2 (-), 3/6 (+)
Output Power: up to 22W
Indicators LED indicators are located on the RJ45 connector
Power indicator: PoE enabled
Network indicator:
Connectors Shielded RJ-45, EIA 568A and 568B
Network cables Shielded category 5 (or higher)
Dimensions 145mm x 60mm x 40mm
Mounting Wall of shelf
Environment Indoor
Environmental Conditions Operating Ambient Temperature: -10 to 45°C
Operating Humidity:
Maximum 90%, Non-condensing
Storage Temperature: -20 to 70°C
Storage Humidity:
Maximum 95%, Non-condensing
Regulatory Compliance IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
RoHS Compliant, CE, FCC
Electromagnetic FCC Part15, Class B
