STEREO INSTRUCTIONS
Important Instructions
1. Never repair the stereo unit yourself. In case of any failure, please turn off the power,
and contact Dimplex North America. This unit is composed of many precision
electronic components. The dismantling or repair may cause damage.
2. Keep the unit away from humidity, dust, steam, smoke, direct sunlight, etc. Do not
use any chemical detergent on unit.
3. Use soft rag to clean the surface of the unit.
4. Store faceplate in dry areas where temperature is
between –10 C to 60 C.
5. Prevent unit from falling or encountering any serious impact.
6. Close the fireplace access panel when not in use, or after operation.
Control Panel Functions
1. Panel Open Button 12. Play Button
2. Eject Button 13. Band Button
3. Select Button 14. Program-Preview/Search-Down
4. Volume Adjustment 15. Program-Next/Search-Up
5. Clock Button 16. Reset
6. Radio Preset 1/Disc Introduction 17. Preset-EQ
7. Radio Preset 2/Disc Repeat 18. Station Auto-Scan
8. Radio Preset 3/Disc Random 19. Auxiliary Button
9. Radio Preset 4 20. Auxiliary Input Jack
10. Radio Preset 5 21. Equal Loudness Compensation
11. Radio Preset 6 22. Power Button
7
5
3
9 10
2
11
12
13
14
15
4
6 8 17 18
19
20
21
Stereo Chassis
