UNPACKING INSTRUCTIONS (FIREBOX)
2. Carefully lay unit on it’s back. (Figure 1)
3. Remove screws from the left and right side of the front glass lower support.
4. Carefully insert the tip of a slot screwdriver between the glass edge and either the left
or right side trim.
5. Using the screwdriver as a lever, gently apply pressure in a downward motion, forcing
the edge of the glass up.
UNPACKING (continued)
6. Remove packing foam from the top of the log set. (Figure 2)
7. Remove strapping and packing material from around the log set.
8. Clean front glass if needed.
9. Re-assemble logset and front glass.
4
Figure 1
Figure 2
