– 2 –
CONTENTS
Specifications 2
Where to position 3
Before use 3
Parts 6
Programming Feature 7
Operation 10
Drainage 11
Maintenance 12
Trouble shooting 14
SPECIFICATIONS
Model no. GDDEKD9
Power supply 220~240V, 50Hz
Humidity Removal capacity 9 L/day
Power consumption
TURBO (high) – 730W
SLEEP (low) – 385W
Electric heating element (max) – 650W
Air volume (max.) 200 m3/h
Fan (Ventilation) Speed 3
Water tank volume 5L
Working temperature range 1 ~ 32ºC
Timer 1 ~ 24 hours
Continuous Drainage Yes
Safety Device Tip-over switch
Size (WxDxH) 340 x 232 x 511 mm
N.W. 7.5 Kg
• Above is measured under RT 30ºC, RH 80%.
• Current & Fuse: F2L250V or T2L250V
Disposal
This product should be taken to our local recycling centre for safety treatment.
Waste electrical and electronic products must not be disposed of with
household waste.
