Dimplex PLXE User Manual

17
ADVANCE
MENU
BACK
ENTER
Timer Mode
User Timer
Home All Day
Out All Day
Away
ADVANCE
MENU
BACK
ENTER
Return
Date/Time
Saturday
31-2-18
07:00
21
°
C
ADVANCE
MENU
BACK
ENTER
Return
Date/Time
Away Set
ADVANCE
MENU
BACK
ENTER
Away
21
°
C
Until
31-02-18
07:00
NOTE:
The Back button can be used to
end the Away Mode countdown
early.
Continuous Heat Modes
A continuous heat mode is effectively a constant Heating On period. The Heater will remain in a continuous heat
mode indenitely until the mode is changed by the User.
Available Continuous Heat Modes
Each continuous heat mode starts with a default Target Temperature value.
• Manual
• Default 21°C
• Can be changed from the Home Screen to any value within the Heater’s Temperature Range.
• Eco
• Default 19°C
• Can be changed from the Home Screen to any value in the Heater’s minimum temperature range (8-18°C)
• Frost Protection
• Default 7°C
• Not User Denable
ADVANCE
MENU
BACK
ENTER
Modes
Timer Mode
Manual Mode
Eco Mode
Frost Protect
ADVANCE
MENU
BACK
ENTER
Manual
21
°
C
ADVANCE
MENU
BACK
ENTER
User Timer
21
°
C
Heating ON
ADVANCE
MENU
BACK
ENTER
Main Menu
Boost
Modes
Settings
To select a continuous heat mode, rst press the Menu button. Use the arrow
keys to highlight ‘Modes’ and press the Enter button. From here, use the arrow
keys to highlight the desired continuous heat mode and press Enter to select.
You will then be returned to the home screen in your chosen mode.

Dimplex PLXE Specifications

General

Type	Electric Panel Heater
Installation	Wall mounted
IP Rating	IP24
ERP Lot 20 Compliant	Yes
Heating Technology	Convection
Remote Control	No
Safety Features	Overheat Protection
Dimensions	Varies by model
Weight	Varies by model
Power Supply	Mains Electric
Power Output	0.5kW, 0.75kW, 1.0kW, 1.5kW, 2.0kW
Voltage	220-240V
