Dimplex PLXE User Manual

5
Energy Related Product Directive
Model Identier(s): PLX050E PLX075E PLX100E PLX125E PLX150E PLX200E PLXC300E
PLX125E
SDM
Height ‘D’ (mm) 430 430 430 430 430 430 430 430
Width ‘C’ (mm) 450 620 620 690 690 860 860 690
Depth ‘E’ (mm) 108 108 108 108 108 108 143 108
‘A’ 116 286 286 356 356 526 526 356
‘B’ 269 269 269 269 269 269 269 269
‘F’ 365 365 365 365 365 365 365 365
Technical Details
Product information according to Ecodesign Regulation (EU) 2015/1188
Model Identier(s): PLX050E PLX075E PLX100E
PLX125E/
PLX125E
SDM
PLX150E
PLX200E PLXC300E
Heat Output
Nominal heat output Pnom 0.50kW 0.75kW 1.00kW 1.25kW 1.50kW 2.00kW 3.00kW
Minimum heat output
(indicative)
Pmin N.A N.A N.A N.A N.A N.A N.A
Maximum heat output Pmax,c 0.50kW 0.75kW 1.00kW 1.25kW 1.50kW 2.00kW 3.00kW
Auxiliary electricity consumption
At nominal heat output elmax 0.00 0.00 0.00 0.00 0.00 0.00 0.00
At minimum heat output elmin 0.00 0.00 0.00 0.00 0.00 0.00 0.00
In standby mode elSB
<0.0005 <0.0005 <0.0005 <0.0005 <0.0005 <0.0005 <0.0005
Type of heat output / room temperature control Type of heat output / room temperature control
Electronic heat charge control with
room and / or outdoor temperature
feedback
Yes
Other control options
Contact details
Glen Dimplex Heating and Ventilation
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF
Tel: 0344 879 3588
This product meets the Ecodesign requirements for an electric storage local space heater. Commission
Regulation (EU) 2015/1188.

Dimplex PLXE Specifications

General

Type	Electric Panel Heater
Installation	Wall mounted
IP Rating	IP24
ERP Lot 20 Compliant	Yes
Heating Technology	Convection
Remote Control	No
Safety Features	Overheat Protection
Dimensions	Varies by model
Weight	Varies by model
Power Supply	Mains Electric
Power Output	0.5kW, 0.75kW, 1.0kW, 1.5kW, 2.0kW
Voltage	220-240V
