Dimplex PLXE User Manual

6
All Models
Controls
Digitally controlled, Electronic Thermostat accurate to (±0.2°C)
Timer modes:
7 Day Programmable User Timer, Out All Day, Home All Day,
Continuous heat modes:
Eco, Manual, Frost Protect
Additional Modes:
Away, Boost, Setback
Controller UI
• Graphical display with RGB backlight
• Capacitive buttons with audio feedback
• User replaceable battery (Coin-Type)
• Open window detection, Adaptive-start, Advance time period
• Wide SP range (7-30°C)
• Bluetooth for software updates
• Child Lock & Heater Lock (PIN-based)
Construction
• Durable epoxy-polyester powder coated steel casing with louvered forward facing grille
• Advanced controls with capacitive sense technology for total exibility of heating
*Note: PLXC300E features a slotted grille
Element Compact, nned, mineral lled sheathed element
Installation • H-frame wall bracket
Safety
• Thermal cut-out. Auto reset type
• Overheat detection
IP Rating IP24
Battery 3V coin cell battery to backup real time clock. Battery life >5 years.
Supply
1.3 metres tted, 3 core for fused spur installation, 1/N/PE ~230-240 V, 50Hz
Class I, with earth wire
Colour / Finish Metal Chassis, Air Outlet Grille & Control Moulding - Trafc White (RAL 9016)
Approvals CE, UKCA, BEAB
Guarantee 2 years
Country of Origin United Kingdom
Manufacturer
Glen Dimplex Heating & Ventilation
(Glen Dimplex UK Ltd.)

Dimplex PLXE Specifications

General

Type	Electric Panel Heater
Installation	Wall mounted
IP Rating	IP24
ERP Lot 20 Compliant	Yes
Heating Technology	Convection
Remote Control	No
Safety Features	Overheat Protection
Dimensions	Varies by model
Weight	Varies by model
Power Supply	Mains Electric
Power Output	0.5kW, 0.75kW, 1.0kW, 1.5kW, 2.0kW
Voltage	220-240V
