Dimplex QM150 User Manual

- 6 -
Operation
The user controls are located on the top right of the
heater.
The heater is fi tted with an adjustable electronic
temperature controller and three buttons.
Programmable timer
1
Display screen
2
‘Menu’ button
3
‘Back’ button
4
Comfort status
5
‘Selector Dial’
6
‘Advance’ button
The minimum room temperature setting is 14°C.
The maximum temperature setting available is 26°C.
A temperature of approximately 20°C represents a
normal room temperature.
It is normal for the fan to stop running for periods of time.
This happens because the room temperature is at or
above the temperature set on the control and the room
does not need more heat at this time.
1
2
3
6
5
4

Dimplex QM150 Specifications

General

Color	White
Control	Manual
Heat Output	1.5 kW
Installation	Freestanding
Heating Technology	Quartz
Adjustable Thermostat	Yes
Overheat Protection	Yes
Tip-Over Switch	Yes
Type	Quartz Heater
Power Input	1.5kW
Weight	4.5kg
Voltage	230 V
