OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
28
Alarm code Description
147 PRESSURE SENSOR N.2 VALUE GREATER THAN THRESHOLD MAX.
149 ANALOG SCISSOR ANGLE CHANNEL A: OPEN CIRCUIT OR SHORT TO GND
150 ANALOG SCISSOR ANGLE CHANNEL A: SHORT CIRCUIT TO PWR
151 ANALOG SCISSOR ANGLE CHANNEL A: ANGLE VALUE LOWER THAN MIN.
152
ANALOG SCISSOR ANGLE CHANNEL A: ANGLE VALUE GREATER THAN
MAX.
153 ANALOG SCISSOR ANGLE CHANNEL B: OPEN CIRCUIT OR SHORT TO GND
154 ANALOG SCISSOR ANGLE CHANNEL B: SHORT CIRCUIT TO PWR
155 ANALOG SCISSOR ANGLE CHANNEL B: ANGLE VALUE LOWER THAN MIN.
156
ANALOG SCISSOR ANGLE CHANNEL B: ANGLE VALUE GREATER THAN
MAX.
160 PIN01, OUT00 REDUNDANT CHECK FAULT
161 PIN02, OUT01 REDUNDANT CHECK FAULT
162 PIN04, OUT02 REDUNDANT CHECK FAULT
163 PIN05, OUT03 REDUNDANT CHECK FAULT
164 PIN08, OUT04 REDUNDANT CHECK FAULT
165 PIN09, OUT05 REDUNDANT CHECK FAULT
166 PIN11, OUT06 REDUNDANT CHECK FAULT
167 PIN13, OUT07 REDUNDANT CHECK FAULT
168 PIN17, OUT08 REDUNDANT CHECK FAULT
169 PIN18, OUT09 REDUNDANT CHECK FAULT
170 PIN21, OUT10 REDUNDANT CHECK FAULT
171 PIN22, OUT POWERRELAY REDUNDANT CHECK FAULT
172 PIN25, OUT BRAKE1 REDUNDANT CHECK FAULT
173 PIN26, OUT BRAKE2 REDUNDANT CHECK FAULT
201 TM1 ERR PUMP CURRENT SENSOR OFFSET
202 TM1 ERR TRAC1 CURRENT SENSOR OFFSET
203 TM1 ERR TRAC2 CURRENT SENSOR OFFSET
204 TM1 ERR LOAD HW PARAMETER
205 TM1 ERR LOAD PARAMETER
210 TM1 ERR POWER SUPPLY OUT OF LIMIT
211 TM1 ERR POWER RELAY STUCK
