OPERATOR’S MANUAL with Maintenance Information
Specifications
15
Model: JCPT0808HD
Height, working maximum
8 m
Height, platform maximum
6 m
Height, stowed maximum
Rails up
2.23 m
Height, stowed maximum
Rails folded
1.87 m
Width
0.83 m
Length, platform retracted
2.48 m
Length, platform extended
3.38 m
Platform dimensions
Platform length × width
2.27×0.81 m
Platform extension length
0.9 m
Maximum load capacity
380 kg
Maximum wind speed
12.5 m/s
Wheelbase
1.87 m
Turning radius (outside)
2.10 m
Turning radius (inside)
0 m
Ground clearance
10 cm
Ground clearance
Pothole guards deployed
1.9 cm
Weight
（See Serial Label）
Machine weights vary with option configurations
Power source
4 Batteries , 6V 225AH
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
240 bar
System voltage
24 V
Tire size
Φ381×127 mm
Airborne noise emissions
<70 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m/s
2
Maximum slope rating,
Stowed position
25%
Maximum side slope rating,
Stowed position
25%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-1.5°,Y-3°
Drive speeds
Stowed, maximum
3.5 km/h
Platform raised, maximum
0.8 km/h
Floor loading information
Tire load, maximum
1000 kg
Tire contact pressure
11.1 kg/cm
2
1086.9 kPa
Occupied floor pressure
1339 kg/m
2
13.1 kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.

DINGLI JCPT1412 Specifications

General

Working Height	14 m
Platform Length	2.44m
Max Capacity	320 kg
Drive Type	Electric
Max Slope	25%
Power Supply	24V DC
Max Gradeability	25%
Tire Type	Solid non-marking
Charging Time	8-10 hours
Control System	Proportional control
