OPERATOR’S MANUAL with Maintenance Information
Schematic
83
JCPT1212HD JCPT1412HD
SV2
1mm
1mm
S1
S2
P
M
T
BRK
RV1
SV1
FR
RV4
CV2
RV3
CV1
1.1mm
SV4
SV3
D3
D2
D1
D4
L
P41
P42
RV5
CV2
0.9mm
1.5mm
Lower valve
NBCY-1001A-11
Lower valve
NBCY-1001B-11
120bar
235bar
3.45bar
RV2=150bar（JCPT1212HD）
RV2=190bar（JCPT1412HD）
180bar
Pump
5802-4-12
Valve 5805-0116R
Tank
Platform loading(Option)
Steer cylinder
Lift cylinder
Upper lift cylinder
Hand pump
5805-0412(960020A10)
