Fault State
In the fault state, a fault code from the list will be displayed flashing at a 1 Hz rate (0.5 seconds on,
0.5 off).
List of Fault Codes
Display
for
Platform
Display for Ground
Description
Description
01
System fault
Main ECU System Fault
Replace Main ECU
02
Communication fault
ECU/Platform Communication
Fault
Check the wiring,
check the
platform/ground
control
08
Left float valve fault
Left float valve fault
check the wiring,
replace the valve.
09
Right float valve fault
Right float valve fault
check the wiring,
replace the valve.
14
Angle Sensor Fault
Angle Sensor Fault
check the wiring,
replace the sensor.
15
Pressure Sensor Fault
Pressure Sensor Fault
check the wiring,
replace the sensor.
20
Chassis start button fault
Chassis Start Switch ON at
power-up
Check the switch,
check the wiring
21
Chassis Choke button Fault
Chassis Choke Switch ON at
power-up
Check the switch,
check the wiring
22
Chassis Up button Fault
Chassis Up Switch ON at
power-up
Check the switch,
check the wiring
23
Chassis enable button Fault
Chassis Lift Switch ON at
power-up
Check the switch,
check the wiring
24
Chassis Down button Fault
Chassis Down Switch ON at
power-up
Check the switch,
check the wiring
25
PCU steer left button fault
Platform Left Turn Switch ON at
power-up
Check the switch,
replace the platform
26
PCU steer right button fault
Platform Right Turn Switch ON
at power-up
Check the switch,
replace the platform
27
PCU enable button fault
Platform Drive Enable Switch
ON at power-up
Check the switch,
replace the platform
28
PCU joystick out of neutral
fault
Platform Joystick not in neutral
ON at power-up
Check the switch,
replace the platform
31
PCU choke button fault
Platform Choke Switch ON at
power-up
Check the switch,
replace the platform
32
PCU start button fault
Platform Start Switch ON at
power-up
Check the switch,
replace the platform
